Single Shipping Container Bathrooms and Locker Rooms | Falcon Structures

Specs

One 20-foot standard height or high-cube (extra 12 inches)
one-trip container
Exterior paint choices from base palette
½-inch PVC paneling over wood framing and batt insulation
One 32-inch by 14-inch privacy window
One 3-foot wide exterior personnel door
One exterior security light adjacent to the personnel door
Vinyl coin flooring throughout
125A capacity panel with 80A exterior disconnect
Three standard 4-foot LED light fixtures
Two duplex 110V outlets
One PTAC unit with 1.5k BTU cooling, 3.5kW heating capacity
One exterior ¾-inch water supply connection for cold water
One exterior 3-inch drainage connection and 2-inch vent connection
One 6.5kw electric tankless water heater
Two toilets with stalls
Three urinals separated by screens
Two sink vanities with mirrors
Two exhaust vent fans

Exterior

Width: 8 feet
Length: 19 feet, 10.5 inches
Height*: 8 feet, 6 inches

Interior

Width: 6 feet, 9 inches
Length: 19 feet
Height*: 7 feet, 6 inches

*Standard height. Actual container may be a high-cube (additional 12 inches) depending on supply.

**All specifications and pricing subject to change without notice.

***Dimensions are approximate, as containers vary from manufacturer to manufacturer.
